• Alu PVC Blister Packaging Machine Specification
  • Alu PVC Blister Packing Machine
  • Tablet Blister Packing Machine Suppliers in India
Request A Quick Quote

Description

Alu PVC blister packaging machine is indispensable to the pharmaceutical industry. It is widely uses in the packaging of capsules, hard gelatins, soft gelatins, tablets, ampoules and other types of oral tablets. Manufactured for precision packaging and ergonomics, the machine is popular because of its hassle-free operation. It has a unique design that ensures unparalleled synchronization of timings between aluminum foil and PVC base and hence it is called Alu PVC blister packing machine.

Pharmaceutical blistering machine offered by us has several advantages including high production outputs and it works on flat forming and rotary sealing principle. The capsule blister packing machine has all contact parts made of AISI 316 while the non-contact parts are made of AISI 304. It is cGMP compliant and has servo web indexing by rigid PLC logic.

Salient Features of Blister Packing Machine

  • cGMP Model.
  • Provide production hence cost effective.
  • Combi packs for better utilization of capacity and packaging materials.
  • Edge to edge cutting to eliminate trim waste between packs.
  • Special purpose tool minimize trim wastage.
  • Continuous blister forming at low temperature by contact heating system.
  • Change parts and settings at front side of machine for ease of operation.
  • Quick change over reduces material wastage and down time.
  • Increased production output by simpler operation technique.
  • Small footprint occupy less space.
  • No need of Air Compressor on some models.
  • Extended guide track system can accommodate up to four feeders to produce multi-product kit packs.

Working Principle of Blister Packing Machine

PVC base film is fetched from the reel and before it is fed into the blister forming unit. Blisters get continuously formed and the web is taken to the sealing station by using a guide track. There is also a suitable automatic filling system provided in the machine. Aluminum foil is also fetched from a different reel and it is fed to the sealing station. Filled and sealed web is fed using an indexing mechanism and the packs are segregated. The collection process begins once the web is sheared off. Our pharmaceutical blistering machine can be connected to collection bins or a conveyor belt depending on your preferences.

For more information related to capsule blister packing machine, feel free to get in touch with our sales team.

Technical Specification of Blister Packing Machine

Model ABP-240
Type of Formation Aluminium + PVC
Machine Speed Up to 150 Strokes/minute (Output depends upon tablet/capsule shape, size, diameter & packing type)
PVC Bade Film
·            Maximum width 225mm
·            Thickness 0.2 to 0.3 mm
·            Max Reel Dia. 440mm
Aluminium Foil
·            Maximum width 221mm
·            Thickness 0.02 to 0.03 mm
·            Max Roll Dia. 210mm
Forming Area
·            Minimum area 210 x 25mm
·            Maximum area 210 x 135mm
Pack Length 217mm maximum
Pack Width 140mm maximum
Forming Depth 12mm
Max. Core Diameter 70mm
Net Weight 1100 Kgs. approx.
Gross Weight 1500 Kgs. approx.

* Power voltage can be adjusted as per customer’s domestic power voltage requirements.
* Rights of technical improvements & modification reserved.
* Illustrations & dimensions are shown for information purpose only.
