Description
Automatic Carton & Pouch Labeling Machine or automatic carton labeler machine manufactured by us ensures that the packaging of your product results in enhanced appearance and makes the product secure as well. This completely automatic machine makes the entire process easy and you can make sure that your product is transported to the end user in a secure manner. We offer various types of carton labelers and automatic pouch labelers with different production speeds to match up with your diverse requirements. Whether you are looking for single side, top side or both side carton labeling machine for empty and filled cartons or with paper labels and transparent labels, you can count on us for productive machines that help you up your game.
We also offer single side and double side carton security sticker labeling machines that offer phenomenal accuracy. Our sophisticated automatic carton labeler can also apply hologram stickers on different sorts of labels as well as film rolls. Front and back labeling systems provided by us are highly durable, easy to operate and efficient. We design and manufacture security label applicator that is SERVO based and has a microprocessor controlled system. It also has a reliable PLC system that makes the entire process a cake-walk for you.
For more information related to our automatic pouch labeler, feel free to get in touch with us.
Features of Pouch Labeling Machine
- Compact & elegant model.
- Apt for Normal Paper Labels, Transparent Plastic Labels as well as BOPP Labels.
- One machine can label Bottles, Jars, Tins & other round containers.
- Optional Printing Device attachment facility.
- No Label Data Input/retrievals require for any Label Size.
- HMI based Touch Screen control panel.
- Different label size working without extra change parts set.
- Speed variation pot inbuilt in control system.
- Synchronized speed of Label Dispensing, Product Feeding and Pressing Device.
- Easy to clean and less maintenance system.
- User Friendly Label Placing Adjustments.
- Online Inkjet and Contact Coding System can be attached.
- Suitable for Partial, Full Wrap Around and Overlap Labeling.
- Variable AC Frequency Drive for speed adjustment.
- Machine cover made from high quality Stainless Steel 304.
Technical Specification of Bottle Labeling Machine
Model | AVSL 80 | AVSL 150 | AVSL 250 |
Vial Sizes | 2ml to 250ml | 2ml to 250ml | 2ml to 250ml |
Speed | Up to 60 Labels per minute depending on container and label characteristics | Up to 120 Labels per minute depending on container and label characteristics | Up to 200 Labels per minute depending on container and label characteristics |
Label Height | 8mm to 90mm | 8mm to 90mm | 8mm to 90mm |
Label Length | 12mm min. | 12mm min. | 12mm min. |
Label Roll Dia. | 400mm | 400mm | 400mm |
Label Roll Core Dia. | 75 / 76mm | 75 / 76mm | 75 / 76mm |
Gap Between two Labels | 3mm approx. | 3mm approx. | 3mm approx. |
Power Load | 1 H. P. | 1.5 H. P. | 3 H. P. |
Power Voltage | 220 VAC Single Phase Power Supply (50/60 Hz) | 220 VAC Single Phase Power Supply (50/60 Hz) | 220 VAC Single Phase Power Supply (50/60 Hz) |
Product Feeding Belt height | 850mm to 950mm adjustable | 850mm to 950mm adjustable | 850mm to 950mm adjustable |
Machine footprint | 1500mm(L) X 1200mm(W) X 1100mm (H) approx. | 2000mm(L) X 1350mm(W) X 1100mm (H) approx. | 2500mm(L) X 1350mm(W) X 1100mm (H) approx. |
* Power voltage can be adjusted as per customer’s domestic power voltage requirements.
* Rights of technical improvements & modification reserved.
* Illustrations & dimensions are shown for information purpose only.
