Description

Cath Lab Ethylene Oxide Gas Sterilizer is one of the key machines commonly uses in pharmaceutical, textile, healthcare and food industries among others. Adinath International is a leading cath lab hospital EO sterilizer manufacturer in India offering cath lab sterilizer equipped with plethora of features.

What is Cath Lab ETO Sterilizer?

Cath lab ETO sterilizer is an ultra-modern sterilizer that is vastly used in the sterilization of medical, surgical and pharmaceutical products. Ethylene oxide sterilization is an advanced method to sterilize medical devices and other heat sensitive devices. As a pioneering cath lab ethylene oxide supplier in India, we provide advanced hospital EO sterilizer that is not only safe to use but eco-friendly as well. A vast array of delicate devices which are otherwise impossible to sterilize by deploying conventional methods can be seamlessly sterilized using this ultra-modern sterilizer.

Working Principle and Sterilization Process

Let’s take a look at the working principle and several stages involved in the sterilization process. Since, there is no standardized process owing to a vast diversity in exposure periods and gas concentration, the process below is a typical one and must be taken into consideration for reference purposes only.

The machine uses single use EO cartridges of 40, 100 and 170 grams. The chamber is facilitated with a single door and a simple locking system. There is an electronically controlled heating system in place to ensure a uniform heating at 50 degrees centigrade. The machine is designed for optimum durability as it contains venturi of adequate capacity inside a robust cabinet. There are control buttons for heating, gas purging and power supply requirements.

  •   Product exposed to warm and humid environment

The product is exposed to a warm and humid environment for about 12 hours.  70 percent RH and 55 A Cº is maintained for a uniform temperature and humidity.

  • Introduction of ETO gas

Now the vacuum is pulled and ETO gas is introduced at this stage. The exposure is for about 4 to 8 hours at the same RH and temperature as before.

  • Removal of ETO gas

Vacuum is continually pulled for the removal of ETO gas and air is introduced into the sterilization chamber to clear out the entire ETO gas. This process lasts for about 8 to 12 hours.

Features of Cath Lab Ethylene Oxide Gas Sterilizer

  • Used to sterilize disposable syringes, I.Vs, disposable surgical set, gloves, infusion sets, urine collecting bags, birth control apparatus and plenty of medical devices
  • Easy to operate
  • Chamber with modular construction
  • IQ, OQ and DQ documentation can be provided
  • Prevention of micro biological contamination
  • Contact parts made of SS 304 and 316

As a leading manufacturer and supplier of cath lab ethylene oxide sterilizer in India, Adinath International offers sterilizers of all sizes, ranging from small ETO sterilizers to room sized sterilizers.

Technical Specification of Hospital EO Sterilizer

Model AETOS – 2.6 AETOS – 4.5 AETOS – 8
Working Capacity in Cu. Ft. 2.6 4.5 8
Working Volume 70 Liters 125 Liters 200 Liters
Chamber Size 12” (W) x 12” (H) x 32”



12” (W) x 12” (H) x 54” (D) OR

15” (W) x 15” (H) x 36” (D)

20” (W) x 18” (H) x 38” (D) OR

16” (W) x 16” (H) x 54” (D)

Sterilant Gas 40 grams cartridge 100 grams cartridge 170 grams cartridge
Sterilization Cycle Warm & Cold Cycles are possible Warm & Cold Cycles are possible Warm & Cold Cycles are possible
Aeration In-built aeration facility provided In-built aeration facility provided In-built aeration facility provided
Utility Compressed Air (100 psig) Compressed Air (100 psig) Compressed Air (100 psig)
Power Supply 1 K.W. 2 K.W. 2.5 K.W.
Power Voltage 220 volts, Single Phase, 50 Hertz 220 volts, Single Phase, 50 Hertz 220 volts, Single Phase, 50 Hertz

* Power voltage can be adjusted as per customer’s domestic power voltage requirements.
* Rights of technical improvements & modification reserved.
* Illustrations & dimensions are shown for information purpose only.
